SJ SERVA SJPETRO Varco NOV SCP TSC Centrifugal Pump
描述
SJ SERVA SJPETRO Varco NOV SCP TSC Centrifugal Pump
TSC Highlight centrifugal pump adopts rugged heavy – duty construction, reducing downtime and total cost of ownership in the drilling industry.
Multiple applications: Made of wear – resistant materials, suitable for handling abrasive media (cements, drilling fluids) in the oil & gas industry and agricultural waste disposal.
Wide operating range: Has 7 fluid end sizes and over 100 impeller specifications, with flow ranging from 160 to 2500 gpm.
Dimensional compliance: Complies with industry – standard dimensional envelopes for oil & gas drilling and well servicing.
Global distribution: Has offices and distributors in major oil & gas regions worldwide.
Extended run time: Wear – resistant fluid end materials extend the service life of critical wear components.
Prevention of costly failures: The 2¼” pump shaft resists impeller – induced deflection to avoid mechanical seal failures.
Optimized fluid flow: Wide – vane impellers improve flow dynamics and increase fluid volume.
Enhanced fatigue resistance: Heavy – duty power end construction enhances overall fatigue resistance by strengthening mass in critical stress areas.
Improved bearing life: Heavy – duty inboard roller bearings provide a larger bearing area, prolonging the life of bearings and mechanical seals.
Reduced maintenance: Optional mechanical seals reduce maintenance workload and optimize long – term maintenance procedures.
Full open impeller: Minimizes induced shaft loading.
Enhanced pump efficiency: Concentric casing reduces turbulence and extends the service life of the fluid end.
| No | Qty | Part No | part# | Description | materials |
| 1* | 1 | See below | See below | Casing | Hard Iron |
| 1A | 1 | 10399-46-1 | TS-10399-46-1 | Gasket,Casing | Vellumoid |
| IB | 12 | 3932-61 | TS-3932-61 | Nut,Casing | Stl |
| IC | 12 | 3862-76 | TS-3862-76 | Stud,Casing | stl |
| ID | 1 | B505-4-1 | TS-8505-04-01 | rlug,Casing Drain | stl |
| 1E | 1 | 8505-4-1 | TS-8505-04-01 | Plug,Flush Line | Iron |
| 2* | 1 | See below | See below | Impeller | Hard Iron |
| 2A | 1 | 19110-72 | TS-19110-72 | Seal,Impeller | Viton |
| 2B | 1 | TS-7300239 | Washer,Impeller | stl | |
| 2C | 1 | TS-7415648 | Bolt,Impeller Lock | Stl | |
| 3* | 1 | 22223-01-30 | TS-22223-01-30 | Stuffing Box,Mech.Seal | Hard Iorn |
| 3* | 1 | 20614-01-30 | TS-20614-01-30 | Stuffing Box,Packed | Hard Iorn |
| 3A | 2 | 3861-117 | TS-3861-117 | Bolt,Stuffing Box | stl |
| 3B | 1 | 19368-01 | TS-19368-01 | Grease Fitting | Bronze |
| 4 | 1 | 20622A | TS-20622A | Gland Assy,Packing | Bronze |
| 5 | 1 | 22451-1 | TS-22451-1 | Seal,Mechanical | Tungsten Carbide |
| 5A | 1 | 25014-04M-B | TS-25014-04M-B | Packing,Shaft | Kevlar |
| 7 | 1 | TS-20612-02-33-S | shaft | AISI 4140 | |
| 7A | 1 | 20943-21 | TS-20943-21 | Sleeve,Shaft(M.S.Pump) | AISI E7140 |
| 7A | 1 | 20613-21G-7A | TS-20613-21G-7A | Sleeve,Shaft(Pack Pump) | AISIE7140 |
| 7B | 1 | 4372-5-21 | TS-4372-5-21 | Key,Shaft | 416SS |
| 7C | 1 | 23444-01-72 | TS-23444-01-72 | Seal,Shaft Sleeve | Viton |
| 8 | 1 | 22210-1A | TS-22210-1A | Deflector Assembly | Bronze |
| 9 | 1 | 20938-02-01 | TS-20938-02-01 | frame | Cast Iron |
| 9A | N/A | ||||
| 9B | N/A | ||||
| 9C | 1 | 38473 | TS-8505-05 | Plug,Oil Drain | Iron |
| 9D | 1 | 24473 | TS-8267-01 | Breather | stl |
| 9E | N/A | ||||
| 9F | 1 | JB/T9740.3-1995 | oil cupo BI8 | Al | |
| 9G | 3 | 2538-1H | TS-2538-1H | Bolt,casing jack | Stl |
| 10A | 1 | 20626 | TS-20626 | Cover,Inboard Bearing | Iron |
| 10B | 1 | 20625 | TS-20625 | Gasket,LB.Bearing Cover | Vegetable Fiber |
| 10C | 1 | 20619-01 | TS-20619-01 | oil Seal,LB.Bearing Cover | Buna-n |
| 10D | 2 | 22282 | TS-3861-1 | Bolt,LB.Bearing Cover | Stl |
| 10E | 2 | 11720 | TS-3932-2 | Nut,LB.Brg.Cover | |
| 10F | NA | ||||
| 10G | 1 | 21641-01 | TS-21641-01 | Grease Fitting | Stl |
| 11 | 1 | N/A | TS-661009010 | Bearing,Inboard | Vendor |
| 12 | 1 | 22224-01-43 | TS-22224-01-43 | Hydraulic Bearing Housing | Stl |
| 12A | 1 | 7496-253 | TS-7496-253 | Seal,o.D.Dearing Iousing | Duna-n |
| 13 | 1 | 20617-01-01 | TS-20617-01-01 | Cover,O.B.Bearing | Iron |
| 13A | 1 | TS-661010020 | Grease Zerk,O.B.Bearing Cvr | stl | |
| 13B | 1 | 7496-26 | TS-7496-26 | O-ring,O.B.Bearing Cover | Buna-n |
| 13C | 1 | 20619-02 | TS-20619-02 | oil Seal,O.B.Bearing Cover | Buna-n |
| 13D | 2 | 3861-139 | TS-3861-139 | Bolt,O.B.Bearing Cover | Stl |
| 14 | 1 | N/A | TS-648408201S | Bearing,O.B. (2 Req’d) | Vendor |
| 14A | 1 | Apr-24 | TS-6124-4 | Lockwasher,O.B.Bearing | stl |
| 14B | 1 | Apr-23 | TS-6123-4 | Locknut,O.B.Bearing | stl |
| 15 | 1 | 22225-01-01 | TS-22225-01-01 | Hydraulic Motor Adapter | Stl |
| 15A | 1 | N/A | TS-2273-1 | Spacer,Hydraulic Motor | Stl |
| 15B | 1 | N/A | TS-HDAGUARDS | Guards,Hydraulic Drive Adapter | 304 |
| 15C | 2 | N/A | Bolt,Adapter Guards | Stl | |
| 15D | 8 | N/A | Bolt,Adapter Spacer | Stl | |
| Casing | |||||
| 1* | 1 | 19203-01-30A | TS-19203-01-30A | Casing,3x2x13 | Hard Iron |
| 1* | 1 | 19205-01-30A | TS-19205-01-30A | casing,4x3x13 | Hard Iron |
| I* | 1 | 19222-01-30A | TS-19222-01-30A | casing,5x4x1l | Hard Iron |
| 1* | 1 | 19122-01-30A | TS-19122-01-30A | casing,6x5x11 | Hard Iron |
| 1* | 1 | 19123-01-30A | TS-19123-01-30A | casing,6x5x14 | Hard Iron |
| I* | 1 | 19763-01-30A | TS-19763-01-30A | casing,8x6x¹1 | Hard Iron |
| 1* | 1 | 19117-01-30A | TS-19117-01-30A | casing,8x⁶x14 | Hard Iron |
| 1* | 1 | 20937-01-30A | TS-20937-01-30A | casing,10x8x14 | Hard Iron |
| Impeller | |||||
| 2* | 1 | 19204-XX-30 | TS-19204-XX-30 | Impeller,3x2x13 | Hard Iron |
| 2* | 1 | 19206-XX-30 | TS-19206-XX-30 | Impeller,4x3x13 | Hard Iron |
| 2* | 1 | 19224-XX-30 | TS-19224-XX-30 | Impeller,5x4x14 | Hard Iron |
| 2* | 1 | 19121-XX-30 | TS-19121-XX-30 | Impeller,6x5xll | Hard Iron |
| 2* | 1 | 19121-XX-30 | TS-19121-XX-30 | Impeller,6x5x14 | Hard Iron |
| 2* | 1 | 19121-XX-30 | TS-19121-XX-30 | Impeller,8x6x1l | Hard Iron |
| 2* | 1 | 19116-XX-30 | TS-19116-XX-30 | Impeller,8x6x14 | Hard Iron |
| 2* | 1 | 21867-XX-30 | TS-21867-XX-30 | Impeller,1Ox8x14 | Hard Iron |
