TPQ Air Thrust Clutch: Engineered for Rigging Excellence
SJ SERVA SJPETRO SJ PETRO 318 POWER GRIP PO CLUTCH,LESS DRIVE RING.W/QUICK RELEASE VALVES,BLANK BORE HUB Clutch WPT W18-PO-300
Introduction
The TPQ Air Thrust Clutch represents the pinnacle of precision engineering for the oil and gas industry, centered on the robust Air Thrust Disk Clutch technology. Designed to meet the extreme demands of rig operations, this clutch system delivers unmatched reliability, efficiency, and durability across diverse applications.
Brand Compatibility & Industry Reach
Our clutch solutions bridge global and domestic expertise:
Foreign Brand Synergy: Compatible with industry leaders like Eaton Airflex, and integrated with renowned names such as WPT, WHICHITA, and Twindisk – ensuring seamless integration into international rig fleets.
Domestic Leadership: Aligned with top Chinese brands including SJPETRO, RGPETRO, TIANJIN DRXK, ZYT, BOMCO, KERUI, and HONGHUA – reflecting trust and compatibility within China’s thriving energy sector.
Application-Centric Design
The TPQ Air Thrust Clutch is categorized to excel in four critical rig scenarios:
Petroleum Rig Clutch: Powers oil extraction operations with consistent torque delivery.
Drilling Rig Clutch: Enables high-performance drilling in deep-well and harsh environments.
Workover Rig Clutch: Supports well maintenance tasks with reliable engagement/disengagement.
Service Rig Clutch: Delivers precision for specialized rig servicing applications.
Model Versatility
Choose from a comprehensive range of models tailored to unique operational needs:
ATD118H • ATD218H • ATD318H • ATD124H • ATD224H • ATD324H • ATD230H • ATD236H
Each model is optimized for specific torque, size, and environmental requirements, ensuring a perfect fit for your rig configuration.
Core Components: Built for Performance
At the heart of the TPQ Air Thrust Clutch lies a suite of precision-engineered parts:
Friction Disk: Ensures stable torque transfer and exceptional wear resistance.
Intermediate Plate: Reinforces structural integrity under heavy loads.
Release Spring: Enables smooth, responsive engagement and disengagement.
Friction Hub: Secures component alignment for consistent performance.
Outer Ring: Enhances assembly stability and longevity.
Why TPQ?
Global Compatibility: Works seamlessly with leading foreign and domestic brands.
Rig-Specific Design: Tailored models for petroleum, drilling, workover, and service rigs.
Durability: Premium materials and precision engineering minimize downtime and maintenance.
For oil and gas professionals seeking a clutch solution that combines innovation, compatibility, and reliability, the TPQ Air Thrust Clutch is the definitive choice. Explore our models today and empower your rig operations with world-class performance.
| W18-PO-300 |
| |—WEX2008058 |
| |—X20-11-005 |
| |—X20-08-059 |
| |—X20-27-003 |
| |—W00-10-100 |
| |—W18-02-103 |
| |—W18-20-100 |
| |—W18-50-101 |
| |—X20-08-052 |
| |—W18-50-100 |
| |—W18-03-103 |
| |—X20-11-003 |
| |—W18-11-105 |
| |—W18-07-900 |
| |—W18-11-104 |
| |—X20-20-006 |
| |—W18-34-104 |
| |—W00-33-918 |
| |—X20-01-081 |
| |—W18-01-123 |
| |—B20-01-013 |
| |—X20-01-000 |
| |—A08010520E |
| |—A08010520C |
| FRICTION DISC,18″ LI/PG CLUTCH,BLANK,5/8″ THICK,WT. 7 LBS. |
| CENTER PLATE,18″ TD STYLE PO POWER GRIP CLUTCH |
| NUT,1/2″ NF FLEXLOC FULL HEIGHT |
| PLATE SEPARATOR W/PIN,BRASS,318 POWER |
| RELEASE SPRING,318 PO POWER GRIP PO,1 5/8″ OD X 5 5/8″ LONG |
| STUD,318 TD STYLE PO POWER GRIP CLUTCH |
| HUB & BACKPLATE,318 TD STYLE PO POWER GRIP CLUTCH,BLANK BORE |
NAMEPLATE,SERIAL NUMBER,BRASS,.032″ X 2″X 3″,SQUARE CORNERS,(4)
1/8″ DIA. HOLES,COPY COLOR NATURAL,BLACK BACKGROUND |
| SCREW,DRIVE,#2 X 3/16″ |
| INSTALLATION,OPERATION AND MAINTENANCE OF PO TYPE CLUTCHS IN ENGLISH |
| INSTALLATION,OPERATION AND MAINTENANCE OF PO TYPE CLUTCHS |
| 318 TD STYLE PO POWER GRIP CLUTCH,W/QUICK RELEASE VALVES,BLANK BORE,LESS DRIVE RING |
| HHCS,.875-9 NC X .88″,GR 3 PLATED,SPECIAL MACHINED |
| PIN,TAPER,#10 X 2-1/2″ ANSI B18.8.2-1978 |
| HHCS,.875-9UNCX3″,GR 8,PLATED,ANSI B18.2.1 |
| WASHER,FLAT,7/8″,SPECIAL,18″ PO STYLE |
| QUICK RELEASE VALVE,1/4-18 NPTF,14″-42″ TD STYLE PO POWER GRIP CLUTCHES |
| FRONT PLATE,18″ TD STYLE PO POWER GRIP CLUTCH |
| DIAPHRAGM,18″ TD STYLE PO POWER GRIP CLUTCH |
| CLAMPING RING,ID,18″ TD STYLE PO POWER GRIP CLUTCH |
| HHCS,.375-16UNCX1.000″,GR 8,YELLOW ZINC PLATED |
| CLAMPING RING,OD,18″ TD STYLE PO POWER GRIP CLUTCH |
| INSULATOR PLATE,18″ TD STYLE PO POWER GRIP CLUTCH |
| PIN,SLOTTED SPRING,HEAVY DUTY,1/2″ X 1″ |
| PRESSURE PLATE,18″ TD STYLE PO POWER GRIP CLUTCH |
SJPETRO#RGPETRO#DFXK#ZYT#BPMCO#LANSHI#NOV#NATIONAL OILWELL WARCO#KERUI#HH#HONGHUA#BAOJI#BOMCO#CPTDC#SJ
