Replacement composite wave panel screen for NOV Brandt VSM300 primary shaker. High flow rate, anti-clogging, corrosion resistant and easy installation for oilfield solids control.
Replacement Primary Screens for Brandt VSM 300 PMD Shaker Composite Frame
描述
Features:
- Mesh Material: stainless steel 304/316/316 L.
- Body Material: Q235 steel/composite.
- Screen Type: pretension, Repairable.
- Screen Angle: 7°.
- Screen Layered: Single, dual or triple layered.
- API RP 13C Designation: API 10 – API 325.
- Color: green, black.
| Wave/Flat | Layers | Weight(Kg) | Mesh Type | Screen Dimensions | |
| Wave | 2/3 | 10.00 | XR/MG | 889x686mm |
1. High strength plastic frame and moderate tension screen cloth that form a reliable whole, so it greatlyenhance the tolerable flow;
2. The screen is divided into several independent small cloths to prevent excessive expansion of local damage.At the same time, with a special rubber plug to repair the damage,it can increase the service life and reducethe use cost;
3. Rapid wedge tension devices make the installation of the composite frame screen more convenient, and savethe time of changing the screen by stop the machine;
4. Excellent polyurethane material of the frame enhance the corrosion resistance of the composite frame screen
greatly.
| API Screen Number | D100 Separation (Microns) |
| API 20 | >780 to 925 |
| API 25 | >655 to 780 |
| API 30 | >550 to 655 |
| API 35 | >462.5 to 550 |
| API 40 | >390 to 462.5 |
| API 45 | >327.5 to 390 |
| API 50 | >275 to 327.5 |
| API 60 | >231 to 275 |
| API 70 | >196 to 231 |
| API 80 | >165 to 196 |
| API 100 | >137.5 to 165 |
| API 120 | >116.5 to 137.5 |
| API 140 | >98 to 116.5 |
| API 170 | >82.5 to 98 |
| API 200 | >69 to 82.5 |
| API 230 | >58 to 69 |
| API 270 | >49 to 58 |
| API 325 | >41.5 to 49 |
| API 400 | >35 to 41.5 |
| API 450 | >28.5 to 35 |
| API 500 | >22.5 to 28.5 |
| API 635 | >18.5 to 22.5 |
