PCS-611A Cementing Equipment Skid Mounted Auto Density Control Single Pump SJS SERVA
描述
PCS-611A Cementing Equipment Skid Mounted Auto Density Control Single Pump SJS SERVA
Skid mounted cementing equipment serves offshore projects and remote onshore locations including desert terrain inaccessible to regular transport vehicles. Operators may select from three primary cementing plunger pump models: TPA400, TPH400 and TPB600, alongside a wide range of plunger sizes to match varying field operating requirements. What’s app +8615972752793Luben@youlongpetro.com Each unit incorporates comprehensive anti-corrosion design suitable for offshore deployment. A Zone-II explosion-proof variant has also been developed to accommodate the operational demands of offshore platforms.
1. Overview
The PCS-611A auto density control single pump cementing skid represents a new-generation cementing unit equipped with extended TPC600 plunger pump and ACM automatic mixing system.
Building upon the advantages of TPB series plunger pumps, the extended TPC600 plunger pump simplifies packing replacement and routine servicing, rendering it an optimal pumping solution for single pump configurations. This skid is fitted with the extended TPC600 plunger pump to facilitate straightforward packing maintenance.What’s app +8615972752793Luben@youlongpetro.com
Mixing power is delivered via a standalone power unit, lifting the usable operating power output of the main engine. The slurry recirculating pump and triplex plunger pump utilise separate power supplies. This arrangement prevents fluctuations in triplex pump pressure or flow rate from compromising final slurry quality.
2. General specification
Max. working pressure: 44MPa (w/4 1/2″ fluid end) Max. flow: 2.1m3/min (w/ 4 1/2″ fluid end) Density range: 1.3–2.5g/cm3 Auto control precision: ±0.02 g/cm3 Mixing capacity: 0.3–2.0m3/min Working ambient temperature: -20°C to 50°C Overall dimension (mm): 6300(L) × 2300(W) × 3100(H) Net weight: 12000kg
| Configuration | |
| Engine | Caterpillar C13 475hp@2100rpm |
| Transmission | Allision 4700 OFS |
| Triplex pump | SERVA TPC600x4.5″ |
| Power unit | Cummins hydraulic power unit 6BT5.9A 180HP @2500RPM |
| Mixing system | High energy recirculating Jet mixing system |
| Density Control system | ACM-lll.1 Auto control system |
| Slurry recirculating pump | Serva RA56 |
| Booster centrifugal pump | Serva RA45 |
| Mxing water pump | Serva RB23 |
| Displacement tank | 2×10 BBL stainless steel tank |
| Mixing tank volume | 1.6m3 |
3. Features
- A dedicated booster centrifugal pump separates the recirculation circuit and booster circuit. Mutual interference between the two systems is eliminated, delivering improved mixing consistency.
- High energy recirculating jet mixing system.
- Off-center dry cement valve effectively prevents bulk cement blockage.
- Emergency kill system of air inlet shutoff.What’s app +8615972752793Luben@youlongpetro.com
- F300 Non-radioactive densitometer allows convenient cleaning while maintaining safe, stable performance.
- Streamlined operating layout conforms to established oilfield operational practices.
- 10″ operation screen enables intuitive real-time monitoring of operational parameters.
- Portable wireless and wired data acquisition system is available as an option.
