P40-44-213 Spring Lock Suction Stop For SJS SERVA TPH400 Halliburton HT400 4.5in Triplex Plunger Frac Pump Fluid End Suction Valve Parts Replacement
P40-44-213 Spring Lock Suction Stop For SJS SERVA TPH400 Halliburton HT-400 Frac Plunger Pump Replacement Fluid End Valve Parts
描述
P40-44-213 Spring Lock Suction Stop For SJS SERVA TPH400 Halliburton HT400 4.5in Triplex Plunger Frac Pump Fluid End Suction Valve Parts Replacement
Description: SPRING,LOCK,NO.4 SUCTION STOP
Part No..: P40-44-213
Application :fracturing, cementing, acid stimulation, well pressure testing, chemical squeezing
We supply well service pumps, covering HT400, TWS600S, QWS1000, TWS2000-2250, QWS2500, QWS2800 and FMC WQ2700 , also supply frac pump spare parts include fluid end parts and power end parts, If you need any part numbers or other configurations of the plunger, contact YOU LONG PETRO for more details.
| SJSPart | Item | Qty | Description |
| P40-44-200 | SUCTIONVALVESUBASSEMBLY,41/2″ | ||
| B01-15-003 | 1 | 1 | PIN,COTTER,5X35GB91 |
| P40-44-213 | 2 | 1 | SPRING,LOCK,NO.4SUCTIONSTOP |
| P40-40-215 | 3 | 2 | BOOT,SUCTION STOP,NO.3,NO.4 & NO.5 VALVE |
| P40-44-215 | 4 | 1 | RETAINER,STOP AND SPRING,NO.4 SUCTION VALVE |
| P40-40-112 | 5 | 2 | INSERT,FOR TWO-PIECE BUSHING,NO.4 VALVE GUIDE |
| P40-44-106 | 6 | 1 | SPRING,VALVE,25LB/IN,STAINLESS,4-IN.AND 4 1/2-IN |
| P40-44-107 | 7 | 1 | VALVE,FRACNO.4FRAC |
| P40-44-108 | 8 | 1 | INSERT,POLYURETHANE,NO.4FRACVALVE |
| P40-44-109 | 9 | 1 | SEAT,VALVE,TAPEREDNO.4FRAC |
| 000P569244 | 10 | 1 | O-RING,NITRILE 90 DURO #244,PEROXIDE CURED |
| P40-44-111 | 11 | 1 | RETAINER,GUIDEBUSHING,NO.4 |
