P40-40-109 Valve Seat For SERVA TPH400 Halliburton HT-400 Triplex Plunger Frac Pump Fluid End Suction & Discharge valve Replacement Parts
P40-40-109 Valve Seat For SERVA TPH400 Halliburton HT-400 Frac Plunger Pump Replacement Fluid End Parts
描述
P40-40-109 Valve Seat For SERVA TPH400 Halliburton HT-400 Triplex Plunger Frac Pump Fluid End Suction & Discharge valve Replacement Parts
We supply well service pumps, covering HT400, TWS600S, QWS1000, TWS2000-2250, QWS2500, QWS2800 and FMC WQ2700 , also supply frac pump spare parts include fluid end parts and power end parts, If you need any part numbers or other configurations of the plunger, contact YOU LONG PETRO for more details.
| SJSPart | Item | Qty | Description |
| P40-40-200 | SUCTIONVALVESUBASSEMBLY | ||
| P40-14-202 | 1 | 2 | PIN,COTTER,1/8″X1 1/2″,SPRING STEEL |
| P40-40-214 | 2 | 1 | SPRING,LOCK,NO.3SUCTIONSTOP |
| P40-40-215 | 3 | 2 | BOOT,SUCTIONSTOP,NO.3,NO.4&NO.5VALVE |
| P40-40-216 | 4 | 1 | RETAINER,STOP AND SPRING,NO.3 SUCTION VALVE |
| P40-40-112 | 5 | 2 | INSERT,FOR TWO-PIECE BUSHING,NO.4 VALVE GUIDE |
| P40-40-106 | 6 | 1 | SPRING,VALVE,36LB/IN |
| P40-40-107 | 7 | 1 | VALVE,FRAC,33/8″ |
| P40-40-108 | 8 | 1 | INSERT,POLYURETHANE,NO.3FRACVALVE |
| P40-40-109 | 9 | 1 | SEAT,VALVE,TAPERED,NO.3FRAC |
| 000P569240 | 10 | 1 | O-RING,NITRILE 90 DURO #240,PEROXIDE CURED |
| P40-40-111 | 11 | 1 | RETAINER,GUIDEBUSHING,33/8″X1/8″ |
