NOV MD Totco Crown Wagner SJPETRO RGPETRO Drilling Instrument JPIM SZJ-I Rotary Table & Pump Stroke Speed Measurement Unit
SZJ-ZS.1-1 2-148 SZJ-ZS.1-2 SZJ-ZS.1-3 SZJ-ZS.1-4 SZJ-ZS.1A-1 SZJ-ZS.1-6 SZJ-ZS.1-7 SZJ-ZS.1A-2 SZJ-ZS.1-9 SZJ-ZS.1-1
SJPETRO#RGPETRO#DFXK#ZYT#BPMCO#LANSHI#NOV#NATIONAL OILWELL WARCO
#KERUI#HH#HONGHUA#BAOJI#BOMCO#CPTDC#SJ
Contact info
What’s app +8615972752793
Luben@youlongpetro.com
The non-contact measurement method is adopted for the rotary table rotational speed and pump stroke speed sensor. The unit is composed of a proximity inductive switch assembly, an inductive metal block, cables, and other components.
When a metal object passes by the inductive surface of the sensor, a pulse signal is generated. This signal is transmitted to the data acquisition unit via cables, which then processes the signal and calculates the current rotary table rotational speed. The result is displayed on the driller’s console display meter and the duty room computer.
| Item | Code | Name |
| 1 | SZJ-ZS.1-1 | Cover |
| 2 | 2-148 | O-ring 9.52×2.62 |
| 3 | SZJ-ZS.1-2 | Junction Box |
| 4 | SZJ-ZS.1-3 | Threaded Sleeve |
| 5 | SZJ-ZS.1-4 | Nut |
| 6 | SZJ-ZS.1A-1 | Screw Rod |
| 7 | SZJ-ZS.1-6 | Threaded Sleeve |
| 8 | SZJ-ZS.1-7 | Nut |
| 9 | SZJ-ZS.1A-2 | Probe Housing |
| 10 | Proximity Switch | |
| 11 | SZJ-ZS.1-9 | Connector |
| 12 | Socket |
| Item | Code | Name |
| 1 | SZJ-ZS.1 | Speed Sensor |
| 2 | SZJ-ZS.2 | Tachometer |
| 3 | SZJ-ZS.3 | Explosion-proof Junction Box |
| 4 | SZJ-ZS.1A | Speed Sensor |
| 5 | Thread Seal Tape |
