Built for standard oilfield operations, the SJPETRO K51201110001 swivel joint adopts 2″ Size, Style 10 configuration and Fig 1502 female-to-male connections. It ensures dependable performance under normal working conditions and is widely used in high-pressure piping and manifold assemblies.
Detail:
| Purchasing No |
K51201110001 |
| Nominal Size (inch) |
2″ |
| Style |
style 10 |
| Working Pressure (MPa/psi) |
105/15000 |
| Service Type |
standard |
| Connection mode |
FIG1502(F×M) |
| Type |
long radius |
Features:
- Swivel joint is a kind of high-pressure fluid control product, which is commonly applied to cementing and fracturing equipment. It is used to change the pipeline connection direction, to make it more convenient and easier to connect the pipe fittings. Luben@youlongpetro.com It is widely used in acid working environments, to connect the high-pressure discharge pipe, suction pipe, temporary flow pipeline, well test line and high-pressure transmission line.
- This swivel joint is a metal pipe adapter installed with rollerbearings based on the introduced technology from FMC andour technical innovation. The swivel joints with size rangingfrom 1″ to 4″ and rated working pressure range of 25~140MPa (3626 psi~20000 psi) are available. What’s app +8615972752793 Various modelsof swivel joints and relevant repair kits for normaltemperature, low temperature and sour gas(H2S)conditions can be provided.We can provide long radius and short radius swivel joints.The long swivel joints can minimize fluid resistance andhave better performance in corrosion resistance than short radius ones due to their smooth bore, but the short radiusswivel joints are needed where the installation space islimited or pressure is low.
Note:
- An insufficient number of swivels or improper make-up for a given installation can lead to unacceptable loads on the entire piping system leading to premature failure of seals or accelerated wear on the product. What’s app +8615972752793 Swivels are not designed for side loading. Loading that will induce a bending moment into the ball races is prohibited.
- To prevent the above, at least three points of rotation are recommended. This will allow the swivel to accommodate the free movement of the lines in all planes. Luben@youlongpetro.com This can be accomplished at a minimum with one style-10 or two style-50 swivels turns.
- It is recommended that a routine maintenance program be followed for replacement of packing and seals, What’s app +8615972752793and that regularly scheduled lubrication is preformed.
YOU LONG PETRO supplies swivel joints with the below part numbers :
We also supply a full range of genuine and interchangeable parts for SPM, FMC, SJ PETRO and other leading brands, including swivel joints, plug valves, repair kits and high-pressure valves. Whether you require standard, H₂S service or custom solutions, we have you covered.
For more oilfield parts, feel free to contact us.What’s app +8615972752793; Luben@youlongpetro.com
| Style |
Purchasing No |
Model |
Size |
Working pressure
(MPa/psi) |
Connection mode |
Environment |
| Style 10 |
K51200810001 |
SWG51-42-2-10 |
2″ |
42/6000 |
FIG602(F×M) |
standard |
| Style 10 |
K51201010005 |
SWG51-70-2-10 |
2″ |
70/10000 |
FIG1002(F×M) |
standard |
| Style 10 |
K51201110001 |
SWG51-105-2-10 |
2″ |
105/15000 |
FIG1502(F×M) |
standard |
| Style 10 |
K51201110004 |
SWG51-105-2-10 |
2″ |
FIG1502(M×M) |
standard |
| Style 10 |
K51150810901 |
SWG51-42-2-10 |
2″ |
42/6000 |
FIGG02(F×M) |
H2S |
| Style 10 |
K51201010901 |
SWG51-70-2-10 |
2″ |
70/10000 |
FIG1502(F×M) |
H2S |
| Style 20 |
K51200820001 |
SWG51-42-2-20 |
2″ |
42/6000 |
FIG602(F×M) |
standard |
| Style 20 |
K51201020001 |
SWG51-70-2-20 |
2″ |
70/10000 |
FIG1002(F×M) |
standard |
| Style 20 |
K51201120001 |
SWG51-105-2-20 |
2″ |
105/15000 |
FIG1502(F×M) |
standard |
| Style 20 |
K51200820002 |
SWG51-42-2-20 |
2″ |
42/6000 |
FIG602(F×M) |
H₂S |
| Style 20 |
K51201020903 |
SWG51-70-2-20 |
2″ |
70/10000 |
FIG1502(F×M) |
H₂S |
| Style 30 |
K51200830001 |
SWG51-42-2-30 |
2″ |
42/6000 |
FIG602(F×M) |
standard |
| Style 30 |
K51201030003 |
SWG51-70-2-30 |
2″ |
70/10000 |
FIG1002(F×M) |
standard |
| Style 30 |
K51201130002 |
SWG51-105-2-30 |
2″ |
105/15000 |
FIG1502(F×M) |
standard |
| Style 30 |
K51200830901 |
SWG51-42-2-30 |
2″ |
42/6000 |
FIG602(F×M) |
H₂S |
| Style 30 |
K51201030901 |
SWG51-70-2-30 |
2″ |
70/10000 |
FIG1502(F×M) |
H₂S |
| Style 50 |
K51200850001 |
SWG51-42-2-50 |
2″ |
42/6000 |
FIG602(F×M) |
standard |
| Style 50 |
K51201050001 |
SWG51-70-2-50 |
2″ |
70/10000 |
FIG1002(F×M) |
standard |
| Style 50 |
K51201150001 |
SWG51-105-2-50 |
2″ |
105/15000 |
FIG1502(F×M) |
standard |
| Style 50 |
K51200850901 |
SWG51-42-2-50 |
2″ |
42/6000 |
FIG602(F×M) |
H2S |
| Style 50 |
K51201050901 |
SWG51-70-2-50 |
2″ |
70/10000 |
FIG1502(F×M) |
H₂S |
| Style 60 |
K51200860001 |
SWG51-42-2-60 |
2″ |
42/6000 |
FIG602(F×M) |
standard |
| Style 60 |
K51201060001 |
SWG51-70-2-60 |
2″ |
70/10000 |
FIG1002(F×M) |
standard |
| Style 60 |
K51201160002 |
SWG51-105-2-60 |
2″ |
105/15000 |
FIG1502(F×M) |
standard |
| Style 60 |
K51201160001 |
SWG51-105-2-60 |
2″ |
FIG1502(M×M) |
standard |
| Style 60 |
K51200860901 |
SWG51-42-2-60 |
2″ |
42/6000 |
FIG602(F×M) |
H₂S |
| Style 60 |
K51201060901 |
SWG51-70-2-60 |
2″ |
70/10000 |
FIG1502(F×M) |
H₂S |
| Style 80 |
K51250880001 |
SWG51-42-2-80 |
2″ |
42/6000 |
FIG602(F×M) |
standard |
| Style 80 |
K51201080002 |
SWG51-70-2-80 |
2″ |
70/10000 |
FIG1002(F×M) |
standard |
| Style 80 |
K51201180001 |
SWG51-105-2-80 |
2″ |
105/15000 |
FIG1502(F×M |
) standard |
| Style 80 |
K51200880901 |
SWG51-42-2-80 |
2″ |
42/6000 |
FIG602(F×M) |
H₂S |
| Style 80 |
K51201080901 |
SWG51-70-2-80 |
2″ |
70/10000 |
FIG1502(F×M) |
H₂S |
