K41300102001 3″ Threaded Fig 100 Hammer Union Interchangeable with WECO FMC

描述

Built as a direct replacement for WECO/FMC Fig 100 unions, the SJPETRO K41300102001 comes with 3″ threaded ends and standard service construction. It provides dependable sealing and smooth operation in general manifold and pipeline applications.

Product Decription:
Hammer unions are mainly used in oil industry in high-pressure pipline connection. They are commonly found in chemical plants, on dredgers, in strip mines and in the oil industry.Size have 1″ to 5″, work the pressure 7Mpa to140Mpa(1000psi-20000psi), the API 6A and 16C cetification, Luben@youlongpetro.com prevent H2S union according to the NACE MR 0175.

Feature:

Thread or welding connection ;
Standard subs are threaded for API line pipe and are Weco interchangeable.
Unions working in H2S environment per NACE MR0175 ;Luben@youlongpetro.com Self-locking ACME thread;
Quick connection and disconnection;
Interchangeable with international standard parts;What’s app +8615972752793 Pressure proof sealing parts;
Identification marks of size and model are printed on thewing nut by die forging, to ensure easy recognition.
The color coding system on Hammer Unions represents the different configurations and pressure ratings.

YOU LONG PETRO supplies Hammer Union with the below part numbers :

We also supply a full range of genuine and interchangeable parts for SPM, FMC, SJ PETRO and other leading brands, including swivel joints, plug valves, repair kits and high-pressure valves. Whether you require standard, H₂S service or custom solutions, we have you covered.

For more oilfield parts, feel free to contact us.What’s app +8615972752793; Luben@youlongpetro.com

Thread Type Union

connection type

Purchasing No.

Model

Size

Working pressure Mpa/psi

Sealing thread

Environment

FIG100

K41300102001

SWG41-7-3

3″

7/1000

3″LP

std.

FIG100

K41400102001

SWG41-7-4

4″

7/1000

4″LP

std.

FIG200

K41100202001

SWG41-14-1

1″

14/2000

1″LP

std.

FIG200

K41200202001

SWG41-14-2

2″

14/2000

2″ LP

std.

FIG200

K41100202002

SWG41-14-3

3″

14/2000

3″ LP

std.

FIG200

K41400202002

SWG41-14-4

4″

14/2000

4″ LP

std.

FIG206

K41400202001

SWG41-14-4

4″

14/2000

4″LP

std.

FIG211

K41300202001

SWG41-14-3

3″

14/2000

3″LP

std.

FIG400

K41100602001

SWG41-28-1

1″

28MPa

1″LP

std.

FIG400

K41300602001

SWG41-28-3

3″

28MPa

3″LP

std.

FIG602

K41100802001

SWG41-42-1

1″

42/6000

1.5″LP

std.

FIG602

K41200802001

SWG41-42-2

2″

42/6000

2″LP

std.

FIG602

K41200803002

SWG41-42-2

2″

42/6000

2-3/8″ TBG

std.

FIG602

K41300802001

SWG41-42-3

3″

42/6000

3″LP

std.

FIG602

K41350803001

SWG41-42-3

3″

42/6000

3-1/2″TBG

std.

FIG602

K41400802001

SWG41-42-4

4″

42/6000

4″LP

std.

FIG602

K41150802901

SWG41-42-1.5

1.5″

42/6000

1.5″LP

H₂S

FIG602

K41200802901

SWG41-42-2

2″

42/6000

2″LP

H₂S

FIG602

K41300802901

SWG41-42-3

3″

42/6000

3″LP

H₂S

FIG1002

K41151002001

SWG41-70-1.5

1.5″

70/10000

1.5″LP

std.

FIG1002

K41201002001

SWG41-70-2

2″

70/10000

2″LP

std.

FIG1002

K41201003001

SWG41-70-2

2″

70/10000

2-3/8″TBG

std.

FIG1002

K41301002001

SWG41-70-3

3″

70/10000

3″LP

std.

FIG1002

K41351003001

SWG41-70-3

3″

70/10000

3-1/2″TBG

std.

FIG1002

K41401002001

SWG41-70-4

4″

70/10000

4″LP

std.

FIG1002

K41150902901

SWG41-70-1.5

1.5″

52/7500

1.5″LP

H₂S

FIG1002

K41200902901

SWG41-70-2

2″

52/7500

2″LP

H₂S

FIG1002

K41300902901

SWG41-70-3

3″

52/7500

3″LP

H₂S

FIG1002

K41400902901

SWG41-70-4

4″

52/7500

4″LP

H₂S

FIG1003

K41401001001

SWG41-70-4

4″

52.5MPa

4″LP

std.

FIG1502

K41101102001

SWG41-105-1

1″

105/15000

1″LP

std.

FIG1502

K41151102001

SWG41-105-1.5

1.5″

105/15000

1.5″LP

std.

FIG1502

K41201102001

SWG41-105-2

2″

105/15000

2″LP

std.

FIG1502

K41201103002

SWG41-105-2

2″

105/15000

2-3/8TBG

std.

FIG1502

K41301102001

SWG41-105-3

3″

105/15000

3″LP

std.

FIG1502

K41301103001

SWG41-105-3

3″

105/15000

3-1/2TBG

std.

FIG1502

K41401102001

SWG41-105-4

4″

105/15000

4″LP

std.

FIG1502

K41201002901

SWG41-70-2

2″

70/10000

2″LP

H₂S

FIG1502

K41301002902

SWG41-70-3

3″

70/10000

3″LP

H₂S

FIG1502

K41351003901

SWG41-70-3

3″

70/10000

3-1/2TBG

H₂S

Tr99×12.7

K41201003002

SWG41-70-2

2″

70/10000

2-3/8TBG

std.

Tr100×12

K41201103001

SWG41-70-2

2″

70/10000

2-3/8TBG

std.

Welding Type Union
connection type	Purchasing No.	Model	Size	Working pressure Mpa/psi	Environment
connection type	Purchasing No.	Model	Size	Working pressure Mpa/psi	Environment
FIG200	K41300202002	SWG41-14-3H	3″	14/2000	std.
FIG200	K41400204001	SWG41-14-4H	4″	14/2000	std.
FIG602	K41200804001	SWG41-42-2H	2″	42/6000	std.
FIG602	K41200004001	SWG41-42-2H	2″	42/6000	std.
FIG602	K41200004002	SWG41-42-2H	2″	42/6000	std.
FIG602	K41300804001	SWG41-42-3H	3″	42/6000	std.
FIG602	K41300004001	SWG41-42-3H	3″	42/6000	std.
FIG602	K41300804003	SWG41-42-3H	3″	42/6000	std.
FIG602	K41400804001	SWG41-42-4H	4″	42/6000	std.
FIG602	K41200804901	SWG41-42-2H	2″	42/6000	H₂S
FIG602	K41300804901	SWG41-42-3H	3″	42/6000	H₂S
FIG602	K41400804901	SWG41-42-4H	4″	42/6000	H₂S
FIG1002	K41201004001	SWG41-70-2H	2″	70/10000	std.
FIG1002	K41301004001	SWG41-70-3H	3″	70/10000	std.
FIG1002	K41401004001	SWG41-70-4H	4″	70/10000	std.
FIG1002	K41500904001	SWG41-70-5H	5″	52/7500	std.
FIG1002	K41200904901	SWG41-52-2H	2″	52/7500	H₂S
FIG1002	K41300904901	SWG41-52-3H	3″	52/7500	H₂S
FIG1002	K41400904901	SWG41-52-4H	4″	52/7500	H₂S
FIG1003	K41401004002	SWG41-70-4H	4″	52.5MPa	std.
FIG1003	K41301004903AA	SWG41-70-3H	3″	70/10000	std.
FIG1502	K41201104001	SWG41-105-2H	2″	105/15000	std.
FIG1502	K41201104003	SWG41-105-2H	2″	105/15000	std
FIG1502	K41301104001	SWG41-105-3H	3″	105/15000	std.
FIG1502	K41201004901	SWG41-105-2H	2″	70/10000	H₂S
FIG1502	K41301004901	SWG41-105-3H	3″	70/10000	H₂S
FIG2002	K41200704901	SWG41-140-2H	2″	140/20000	std.
FIG2002	K41301204001	SWG41-140-3H	3″	140/20000	std.
FIG2202	K41201104901	SWG41-105-2H	2″	105/15000	H₂S
FIG2202	K41301104901	SWG41-105-3H	3″	105/15000	H₂S
FIG2202	K41401104001	SWG41-105-4H	4″	105/15000	H₂S
Tr120×6	K41200704001	SWG41-35-2H	2″	35/5000	std.
Tr150×6	K41300704002	SWG41-35-3H	3″	35/5000	std.
Tr180×8	K41400704001	SWG41-35-4H	4″	35/5000	std.
