Scalping replacement screen for Brandt VSM300 shaker, heavy duty for coarse drilling cuttings separation.
For Brandt NOV VSM 300 Scalping Shaker Screen Replacement
描述
Description:
- Mesh Material: stainless steel 304/316/316 L.
Body Material: Q235 steel/composite.
Screen Type: pretension, repairable.
Screen Layered: dual or triple layered.
API RP 13C Designation: API 10 – API 325.
Color: green, black.
Wave/Flat Layers Weight(Kg) Mesh Type Screen Dimensions Flat 2/3 12.00 XR/MG 935x675mm
Features:
1. The stainless steel wire cloth combined directly bonded on the metal plank, then tightly bonded together bymetal frames and metal plank.
2. Every layer of wire cloth has different meshes, accurately and reasonably making screening more micromesh.
3. It forms a reliable whole, with high-strength metal frame, reinforced supports and moderate tensionscreening cloth, which greatly enhances the tolerate flow, strength and working life.
| API Screen Number | D100 Separation (Microns) |
| API 20 | >780 to 925 |
| API 25 | >655 to 780 |
| API 30 | >550 to 655 |
| API 35 | >462.5 to 550 |
| API 40 | >390 to 462.5 |
| API 45 | >327.5 to 390 |
| API 50 | >275 to 327.5 |
| API 60 | >231 to 275 |
| API 70 | >196 to 231 |
| API 80 | >165 to 196 |
| API 100 | >137.5 to 165 |
| API 120 | >116.5 to 137.5 |
| API 140 | >98 to 116.5 |
| API 170 | >82.5 to 98 |
| API 200 | >69 to 82.5 |
| API 230 | >58 to 69 |
| API 270 | >49 to 58 |
| API 325 | >41.5 to 49 |
| API 400 | >35 to 41.5 |
| API 450 | >28.5 to 35 |
| API 500 | >22.5 to 28.5 |
| API 635 | >18.5 to 22.5 |
