Reputed International manufacturer is EATON.
Reputed Chinese manufacturer as follow,DALIN,HANDONG,Rubflex
I. Eaton Airflex Pneumatic Clutch Series
(A) VC Series (Heavy-Duty, 5.2bar)
Positioning: Designed for heavy-duty applications in mining, metallurgy, etc., featuring high torque ratings.
Models & Key Specifications:
- 5VC500 (3,050Nm), 14VC500 (4,430Nm), 16VC600 (7,350Nm), 20VC600 (10,500Nm), 24VC650 (13,300Nm), 28VC650 (20,600Nm), 33VC650 (28,800Nm), 37VC650 (36,200Nm), 42VC650 (42,900Nm).
Features: Large dimensions, multi-bolt configuration, Eaton-exclusive mounting hole codes (e.g., 2003/8/18).
(B) CB Series (Medium-to-Heavy-Duty, 5.2bar)
Positioning: Optimized for medium-duty applications such as conveyors and pumps, prioritizing compact installation.
Basic Models:
- 3CB150 (40.7Nm), 4CB200 (113Nm), 5CB200 (165Nm), 6CB200 (231Nm), 8CB250 (485Nm), 10CB300 (921Nm), 12CB350 (1,500Nm), 14CB400 (2,230Nm).
Extended Models (High Torque):
- 16CB500 (3,980Nm), 18CB500 (4,970Nm), 20CB500 (6,060Nm), 22CB500 (7,040Nm), 24CB500 (8,480Nm), 26CB525 (10,400Nm), 28CB525 (12,000Nm), 30CB525 (13,700Nm), 32CB525 (15,500Nm), 36CB525 (19,400Nm), 40CB525 (23,800Nm), 45CB525 (29,400Nm).
Features: Wide torque range, mounting holes compatible with both Eaton and standard codes, dimensions scaled with torque ratings.
II. General-Purpose Series (LT/DY/CBC Series, Multi-Brand Compatibility)
(A) LT Series (Heavy-Duty Variable Conditions, Dynamic Performance Focus)
Positioning: Engineered for heavy-duty, variable-speed applications in mining and metallurgy, requiring precise air supply matching.
Models & Key Specifications:
- LT500/200, LT500/250, LT600/250, LT700/250, LT800/250, LT900/250, LT1070/200, LT1170/250, LT1120/300, LT1250/300, LT965×305, LT1168×305, LT300/100, LT400/125, LT500/125, LT600/125, LT700/200, LT800/135.
Features: Dual torque ratings (rated/limited), specified speed ranges, explicit pneumatic volume/pressure parameters, connection tolerances (e.g., Φ300H8).
(B) DY Series (Single Model, Medium-to-Heavy-Duty)
Positioning: Tailored for specific medium-to-heavy-duty equipment requiring air supply adaptation.
Model: DY700/135 (Rated: 907–1,092Nm; Limited: 24,560–35,360Nm; 5.2bar).
(C) CBC Series (Single Model, Medium-to-Heavy-Duty)
Positioning: Designed for medium-to-heavy-duty transmissions with air supply compatibility.
Model: CBC700/135 (Rated: 687–881Nm; Limited: 22,350–32,660Nm; 5.2bar).
Summary of Core Differences
| Dimension |
Eaton VC/CB Series |
General-Purpose LT/DY/CBC Series |
| Brand Compatibility |
Eaton-exclusive, ecosystem-integrated |
Multi-brand adaptable, independent design |
| Performance Focus |
Static mounting specifications (dimensions, holes) |
Dynamic performance (speed, dual torque) |
| System Integration |
Implicit air supply parameters (@5.2bar) |
Explicit pneumatic volume/pressure |
| Mounting Precision |
Eaton-specific codes (e.g., 2003/8/18) |
Engineering tolerances (e.g., Φ300H8) |
