描述
| Part Number |
Working Load |
Load Cell Part |
Load Cell Type |
| CD204 – 1 |
3000LBS |
CTC102 – 1 |
Tension |
| CD204 – 2 |
6000LBS |
CTC102 – 1 |
Tension |
| CD268 |
7000LBS |
CCC108 |
Compression |
| CD268 – 1 |
8000LBS |
CTC104 |
Tension |
| CD205 – 1 |
15000LBS |
CCC101 |
Compression |
| CD205 – 2 |
30000LBS |
CCC101 |
Compression |
| CD205 – 3 |
40000LBS |
CCC101 |
Compression |
| CD401 |
|
|
|
| CD200 |
|
|
|
Our product range encompasses a comprehensive selection of M/D Totco products, spanning various instrumentation and components critical for drilling operations.
The M/D Totco lineup includes recorders such as the model with Part No. M252A-115, featuring the technical parameter RCDR SYS, PORT 300629. The ISMI master module (H12010A) is specified as MDL, ISMI, MASTER. For tension monitoring, the tong tail rope tension meter, sensor, and pipeline (H6EP-3130) comes with the specification IND, 6″, T/T, 25K LB, 30′ HOSE, P/M W/REMOTE DAMPER. Hydraulic quick disconnect couplings are available in both male (J10900A-02: COUPLER, FEM, 17K PSI, 1/4″ FNPT) and female (J10900A-20: COUPLER, M, 17K PSI, 1/4″ FNPT) variants. Hydraulic hoses include J234-25 (HOSE ASSY, 1/4″X 25′, 5K PSI), J234-30 (HOSE ASSY, 1/4″X 30′, 5K PSI), J234-50 (HOSE ASSY, 1/4″X 50′, 5K PSI), and the weight indicator hydraulic hose J234-75 (HOSE ASSY, 1/4″X 75′, 5K PSI).
The LM2000 rope monitor (LM2-1G-Series) is equipped with a Dash Mount Enclosure made of Stainless Steel, while the display PCB board (PCB287A-01) is a PCBA, LCD TYPE 1, W/BACKLITE. Hydraulic instrument oil options include W15-1 (FLUID, INSTRUMENT QUART) and W15-4 (FLUID, INSTRUMENT GALLON). The weight indicator WA71-32 features the parameter IND, 12″, TTL&BT.WT, P/M, 340KN SLP, 10/12 LS, ENG/SI METRIC. Recorder paper Y45A is a CHART, CIRC 0-15000PSI, and the standpipe pressure sensor manual oil filler pump (YA2) is a HAND PUMP, SWIVEL ADPTR.
A variety of M/D Totco meters are available, with Part Nos. including WO-21389, W3602-45, SN-W58112, M365-310, and GA58-15 (GA58-15 is 1500PSI\TOTCO, with this model listed twice). The M/D Totco mechanical pressure gauge M365-ORD-02-B is also offered. Additional M/D Totco products include the tensioner 212371-1000, wire rope pressure sensor TCE-100K-E8565-01, ultrasonic sensor 222573-001, weight indicator AWE9H-17, motor M3286, and FA-9 series hydraulic-mechanical rotary table torque meter. Also included are the pump stroke sensor 232389, pump pressure sensor E17-152, mud pump standpipe manifold pressure sensor E17-152, rotary table torque meter GHT101A-000001, sensor cup XF150L, ultrasonic level sensor 40224300-004, and communication cable 949921-043.
Further M/D Totco offerings include quick coupling (female) Z3781150100007, quick coupling (male) Z3781150100008, sensor Z3781150100017, torque meter Z3810040000151, pressure gauge Z3781150100015 (model: GA26B-45), pressure gauge Z378115010001 (model: GA60A-80), torque meter GA26B-5 (324120), weight indicator sensor TYRE-E80 (308240), sensor adapter J10900A-20 (324197), adapter J10900A-20 (308240), torque meter GA26B-5, power board GLC65B, and weight indicator HXJ90 (TYPE FS WEIGHT INDICATOR WHPX, with HXJ90 listed twice).
Other M/D Totco products consist of union 97AH2011, digital board 40219493-102, standpipe pressure sensor 20B6A00CS4002, hand-push instrument oil pump 212450-101, ultrasonic level sensor 222573-001, tensioner 212371-1000, pressure sensor package DB107A-E8920-B, mechanical pressure gauge M365-ORD-02-B, 40224300-004, energy consumption brake over-temperature switch OT1 RS228-2529, sensor E80, union 97AH2011, flow sensor 40223750-114, recorder M365-410, recorder pen (red) 935705-011-RED, and recorder pen (blue) 935705-015-BLUE.
Specific component details include the proximity/pump stroke sensor 232389 (PROXIMITY SNSR ASSY (UL)), tong sensor 212371-1000 (LOAD CELL ASSY, 6.53 T F/S, S/N), outlet flow sensor 270701-103 (MUD FLOW SNSR, ELEC), rotary torque sensor 40218041-002 (ROTARY TORQUE SNSR, ELEC. SERIAL NO.: 0825019), LM2000 rope monitor power supply 40223556-001 (with the description: “The Power Supplies will be powering the display”), outlet flow sensor 40224227-005 (MUD FLOW SNSR, LAND RIG SERIAL NO.: 0828944), torque meter 42TDP-002 (with “MANUAL INCLUDED AT NO CHARGE”), standpipe pressure sensor rubber cup E40 (CUP, MUD DIAPHRAGM RUBBER) and E40-1, weight indicator sensor capsule E57-30 (DIAPHRAGM, TNSN CELL SNSR, 37.7″), and suspension weight sensor (pressure transmission package) E80 (CELL, SENSATOR).
Pressure-related instruments from M/D Totco include the pressure gauge GA113-21 (IND, 6″, 35 MPA), torque meter GA113-5 (IND, 6″, 5K PSI), tong pressure gauge GA114-43 (IND, 6″, T/T, 9K KG, 4921 PSI), torque meter GA114-70 (IND, 6″, T/T, 25K LB, 3828 PSI), pressure gauge GA58-46 (GA ASSY, 6″, 6K PSI/40K KPA), pressure gauge GA60A-160 (GA ASSY, 6″, COMP 16,000 PSI), and pressure gauge, pressure sensor, and pipeline set GM6AP-6074 (MUD PMP SYS, 6K PSI). The digital keypad assembly H11062A is a KEYBOARD ASSY, 16 KEY, SPEC.SYS.
Beyond M/D Totco, our drilling instrumentation product portfolio spans a diverse range of models and components, covering foreign brands such as Martin Decker, MT, TOTO, Crown, Barton, Graphic Controls, and ROTOTHERM, as well as domestic brands JPIM and ZHONGHENG. This includes weight indicators in models like JZ900, JZ500, JZ500A, JZ400, JZ400B, JZ250, JZ200, JZI50A, JZ150, JZ100, JZ100A, JZ60, JZ40, JZ82, and JZ75; the MP series (e.g., MP-3000-1HR, MP-3000-150F-50DIV, MP-1000-1HR, MP-30000-1HR, MP-3000-150F-1HR, MP-15000-1HR); load cells with part numbers CD204-1, CD204-2, CD268, CD268-1, CD205-1, CD205-2, CD205-3, CD401, and CD200; complementary parts like diaphragms (JZG72.3-4, JY246-10, JY248-10, JZG18.1.5-3, JZG15.1.4-3, JZ40.1.2.4); valve and sealing components (washer JY246.2.6-8, O-ring 7×2 JY246.2.6-3, sealing ring JY248.2-4, O-ring 4.47×1.78 2-008); and consumables (plastic recording stylus YSB-N, recording paper, 45# transformer oil).
