BCS-300-100 Manual Batch Mixing Skid Equipment SERVA
1. Overview
The BCS-300-100 manual batch mixing skid serves as a cost-effective mixing unit built around continuous and batch mixing architecture. This model excludes the ACM control system and is engineered for batch preparation of cement slurry in well cementing operations.
Working principle: The recirculating centrifugal pump maintains constant slurry circulation. Luben@youlongpetro.com Bulk cement or dry additives are fed into the circulating pipeline through the jet nozzle and dry cement valve mounted on the tank top. Operators can select tank layout options, including a single 120BBL batch mixing tank or dual 2×50BBL tank setup.WhatsApp+8615972752793
Optional Configuration
Mixing system: High energy mixing system
Power system: Centrifugal pumps and agitators can be driven directly by electric motors. This layout enables the unit to satisfy Zone-II explosion-proof requirements.Luben@youlongpetro.com
2.General Specification
| manual batch mixing | single tank | double tank |
| gross weight | 13t | 11t |
| batch mixing tank volume | 120BBL | 2x50BBL |
| density range | 1.2-2.7 g/cm3 | 1.3-2.7 g/cm3 |
| working asmbinet temperature | -25ºC-50ºC | -25ºC-50ºC |
Configuration
| Single tank | Double tank | |
| Engine | ar C7 300HP@2200RPM | lar C7 300HP@2200RPM |
| Gear box | Funk 59000series | Funk 59000series |
| Hydraulic system | Eaton heavy-duty close-loop hydraulic system | Eaton heavy duty close-loop hydraulic system |
| Recirculation centrifugal pumpl | SERVA RA56 | SERVA RA56 |
| Recirculation centrifugal pumpll | SERVA RA56 | SERVA RA56 |
| Ejection system | Simple jet system+ hopper | Simple jet system+ hopper |
| Dry cement valve | Manual control | Manual control |
| Batch mixing tank | single tank+agitator | Double tank+agitator |
3. Features
Cost-efficient design; standard version comes without ACM system and high energy mixing system.WhatsApp+8615972752793
Supports widely adopted international tank layouts: single tank or 2×50BBL dual tanks. Every tank is fitted with high-power agitators.
Equipped with impact-resistant lifting frame, simplifying site transportation and hoisting operations.
Fitted with high-efficiency, water-saving semi-automatic tank cleaning system.Luben@youlongpetro.com
When configured with electric motor drive, the unit fulfills ZONE-II hazardous area standards and can be deployed on offshore platforms.
