BACTLR-300-100 Continuous And Batch Mixing Trailer Equipment SERVA
描述
BACTLR-300-100 Continuous And Batch Mixing Trailer Equipment SERVA
1. Overview
Developed based on real oilfield operational requirements, the BACTLR-300-100A continuous batch mixing trailer delivers premium slurry preparation supporting both continuous and batch mixing modes.Luben@youlongpetro.com
Two additional mechanical support jacks are fitted at the trailer rear end to provide sufficient load-bearing capacity during mixing operations. The on-board engine provides power for the entire mixing assembly.WhatsApp+8615972752793 It drives the hydraulic system to operate three centrifugal pumps and tank agitators. This unit is widely deployed for cementing operations requiring tight control over slurry density consistency.
2. General Specification
Engine power: 300HP@2200 RPM Mixing capacity: 0.3~2.3m³/min Density range: 1.3~2.5g/cm³ Auto control precision: ±0.02 g/cm³ Batch mixing tank volume: 2×50BBL / 2×8 m³ Mixing tank volume: 8BBL / 1.2 m³ Working temperature: -20°C~+50°C Overall dimension (mm): 11600(L) × 2500(W) × 4150(H) Net weight: 22000kg
Standard Configuration
Trailer chassis: Domestic or imported trailer chassis Engine: Caterpillar C7 300HP@2200RPM Gear box: Funk 59000 series Hydraulic system: Eaton heavy-duty closed-loop hydraulic system Slurry recirculating pump: Serva RA56 Booster/transfer pump: Serva RA56 Mixing water pump: Serva 4X3 Mixing system: High energy mixing system Control system: ACM-III.1 auto density control mixing system
3. Features
Additional mechanical jacks offer reliable load bearing when carrying out mixing work.
Supports continuous mixing and batch mixing modes, with switchable manual and automatic control.Luben@youlongpetro.com
Equipped with advanced high energy mixing technology. WhatsApp+8615972752793 After initial homogenization within the high energy mixing system, slurry flows into batch mixing tanks for further averaging to sustain stable slurry quality.
Features widely adopted international 2×50BBL tank layout, and each tank is equipped with high-power agitators.
Fitted with high-efficiency, water-saving semi-automatic cleaning system for batch mixing tanks.
