BACS-300-100A Batch And Continuous Cement Mixing Skid Equipment SERVA
描述
BACS-300-100A Batch and Continuous Cement Mixing Skid Equipment SERVA
1. Overview
The BACS-300-100A batch & continuous mixing skid incorporates ACM-III advanced mixing and density control technology. This unit supports both batch mixing mode and continuous slurry delivery to cementing pumpers to satisfy diverse field operation requirements.
2. Work Process
Continuous mixing mode Prepared cement slurry flows from the mixing tank through the transfer pump and directly feeds the suction side of the triplex pump.
Batch mixing mode Slurry is alternately diverted into two batch mixing tanks. Cyclic switching between tanks enables batch preparation while maintaining uninterrupted slurry supply.WhatsApp+8615972752793
Special slurry mixing mode For special formulation slurries including high-density cement slurry, standard-density base fluid can be loaded first. Weighting additives are fed through the top hopper, and the fluid undergoes full circulation inside the unit driven by the recirculating pump. Luben@youlongpetro.com
3. General Specification
Engine power: 300HP@2200 RPM Mixing capability: 0.3–2.3 m³/min Density range: 1.3–2.5 g/cm³ Auto control precision: ±0.02 g/cm³ Batch mixing tank volume: 2×50BBL / 2×8 m³ Mixing tank volume: 8BBL / 1.2 m³ Working ambient temperature: -20°C ~ +50°C Overall dimension (mm): 7850(L) × 2500(W) × 3150(H) Net weight: 11,500 kg WhatsApp+8615972752793
Standard Configuration
Engine: Caterpillar C7 300HP@2200RPM Gear box: Funk 59000 series Hydraulic system: Eaton heavy-duty closed hydraulic system Slurry recirculating pump: Serva RA56 Booster/transfer pump: Serva RA56 Mixing water pump: Serva 4X3 Mixing system: High energy mixing system Control system: ACM-III.1 auto density control system Luben@youlongpetro.com
4. Features
Supports dual operation modes: continuous mixing and batch mixing; available with manual or automatic control.
Adopts upgraded high energy mixing technology. Cement slurry passes through the high energy mixing system before entering batch tanks for further homogenization, securing consistent slurry quality.WhatsApp+8615972752793
Configured with internationally standard 2×50BBL batch tanks, each fitted with high-power agitators.
Built-in shock-resistant structural frame with lifting lugs, convenient for transportation and hoisting operations.
Equipped with efficient, water-saving semi-automatic tank cleaning system.
