ACD 3-GUPD Nitrogen Reciprocating Pump 50888 1.25inch Cold End Assembly Parts
描述
ACD 3-GUPD Nitrogen Reciprocating Pump 50888 1.25inch Cold End Assembly Parts
COLD END ASSY, 1.25 DIA X 1.3 & 1.5 STROKE 17,000 PSI GUPD 50888
| 10323-2 | NUT-LOCK |
| 10340-1 | ADAPTER PISTON COUPLING |
| 10339-1 | NUT PISTON COUPLING |
| 10339-1 | NUT PISTON COUPLING |
| 49454-1 | RIDER RING, GUPD, DISCHARGE POPPET |
| 49455-1 | POPPET, DISCHARGE, GUPD |
| 14687-1 | SPRING DISCHARGE (SCD) |
| 10353-1 | RING, RIDER, 1.25 DIA LMPD |
| 782329-4 | RING, PISTON, 1.25 DIA X 15 K |
| 10352-1 | EXPANDER, PISTON RING, 1.25 DIA GMPD |
| 15526-1 | RING-SEAL |
| 15527-1 | SEAL, HAT Luben@youlongpetro.com |
| 48783-4 | SPRING, BELLEVILLE |
| 15536-2 | NUT, PACKING GLAND, 1.6250 DIA GMPD |
| 15541-1 | ADAPTER SCRAPER |
| 15563-1 | PISTON ADAPTER 1.625 DIA GMPD |
| 17212-2 | LINER- NUT Luben@youlongpetro.com |
| 44412-2 | RING, JAM, HEAD, GUPD PUMP |
| 44418-1 | GASKET, HEAD |
| 51099-1 | GASKET DISCHARGE GUPD |
| 44417-1 | PISTON, 1.25 DIA 17,000 PSI PUMP |
| 44451-1 | PLATE, SUCTION VALVE, 1.625 & 1.25 DIA |
| 44452-1 | SPRING, SUCTION (SCD) |
| 51098-1 | HEAD, GUPD What’s app +8615972752793 |
| 44414-1 | SLEEVE, CYLINDER, 1.25 DIA GUPD |
| 44455-2 | CYLINDER GUPD 1.625 DIA |
| 51097-1 | FITTING DISCHARGE GUPD |
| 15522-1 | SPACER SEAL 2.00 DIA LMPD |
| 00816-8C | NIPPLE 0.5000 TUBE OD TO 0.3750 NPTM X |
| 00816-12C | NIPPLE 0.7500 TUBE OD TO 0.7500 NPTM X |
| 85020 | RING, RETAINING 2.016 FREE OD X 0.118 |
| 84133 | O RING 1.81250 INCH ID X 2.00000 INCH |
| 56032-1 | CAPSCREW, .375-16 UNC-2A ALLEN HEAD FL |
| 86007 | RING, SCRAPER 1.907 OD X 1.618 ID BRON |
| 87129-302 | SEAL, GLAND SPRING LOADED Tef RING FITS |
| 51798-1 | ADAPTER, PISTON GUPD/HYDRA-RIG |
| 44414-1K | SLEEVE, CYLINDER, 1.25 DIA-GUPD |
| 44455-2K | CYLINDER GUPD 1.625 DIA CHEMICAL & MEC |
| 44412-1K | RING, JAM, HEAD, GUPD PUMP, CHEMICAL A |
| 51098-1K | HEAD, GUPD CHEMICAL AND MECHANICAL PRO |
| 51097-2K | FITTING DISCHARGE GUPD CHEMICAL AND ME |
| 56032-1K | CAPSCREW, .375-16 UNC-2A ALLEN HEAD FL |
| 08501-570 | CONNECTOR, MALE 1/2 TUBE OD X 3/8 NPTM |
| 08501-564 | CONNECTOR, MALE 3/4 TUBE OD X 3/4 NPTM |
| 65608-001 | PLATE, BEARING-GU What’s app +8615972752793 |
