65D Emergency Safety Calipers For PS Series Disc Brake
65D Emergency Safety Calipers For PS Series Disc Brake
描述
65D Emergency Safety Calipers For PS Series Disc Brake
| Sn | Part No | Description | Q-ty |
| BK-0-6D | Emergency caliper | ||
| 1 | BK-1-6A | Brake pad | 2 |
| 2 | BK-11-D1 | washer | 12 |
| 3 | BK-11-S1 | Hexagon head bolt | 12 |
| 4 | BK-2-6C | Steel backing | 2 |
| 5 | BK-3-6C | Sleeve | 4 |
| 6 | BK-4-6C | Clevis pin with head | 2 |
| 7 | BK-3-6C1 | Sleeve | 4 |
| 8 | BK-5-6D | Lever | 2 |
| 9 | BK-6-6A | Cover plate | 4 |
| 10 | BK-11-S2 | Slotted countersunk head screw | 8 |
| 11 | BK-4-6C1 | Clevis pin with head | 2 |
| 12 | BK-3-6C2 | Sleeve | 4 |
| 13 | BK-12-Q3 | Circlip for shaft | 4 |
| 15 | BK-7-6C | Emergency caliper cylinder assembly | 1 |
| 16 | BK-3-6C3 | Sleeve | 4 |
| 17 | BK-3-6C5 | Sleeve | 4 |
| 18 | BK-4-6C2 | Clevis pin | 4 |
| 19 | BK-8-6A | Semicircle retaining ring | 4 |
| 20 | BK-11-S7 | Hexagon head bolt | 8 |
| 21 | BK-12-04 | Circlip for shaft | 4 |
| 22 | BK-9-6C | Support arm | 2 |
| 23 | BK-10-6A | baffle plate | 4 |
| 24 | BK-11-D3 | washer8 | 8 |
| 25 | BK-3-6C4 | Sleeve | 4 |
