2A17298 Style 30 Swivel Joint 2″ 1502 Fig MxF H2S Service For Weir SPM Chiksan

描述

This Weir SPM Chiksan 2A17298 swivel joint features 2 inch 1502 union male-female Style 30 connections with 15000 psi rating for H2S/sour gas service. Engineered for reliable multi-plane rotation and consistent fluid flow, it ensures long service life in corrosive high-pressure oilfield applications.

Features:
1.SPM swivels are available in 2” through 4” sizes and in pressure ratings up to 15,000 psi. All SPM swivels feature uniform wall thickness throughout for consistent flow of fluids and extended life. Designed for optimized distribution of material for female ball race components, Luben@youlongpetro.com the ball bearing connection of SPM swivels are robust while providing consistent rotation.
2.SPM swivels are available in a wide variety of “styles” providing optimal performance in a variety of installations. What’s app +8615972752793Rotation of the swivels will vary based on configuration, with options available to provide movement in numerous planes.
3.The 3” 1502 swivels and 4” 1002 swivels are gauged during manufacturing to enable them to pass a 2.5” and 3.5” frac ball respectively.

NOTE:
1.Weir’s standard swivel offering is not intended for use in applications requiring continuous rotation.
2.An insufficient number of swivels or improper make-up for a given installation can lead to unacceptable loads on the entire piping system leading to premature failure of seals or accelerated wear on the product. Swivels are not designed for side loading. What’s app +8615972752793Loading that will induce a bending moment into the ball races is prohibited.
3.To prevent the above, What’s app +8615972752793at least three points of rotation are recommended. This will allow the swivel to accommodate the free movement of the lines in all planes. This can be accomplished at a minimum with one style-10 or two style-50 swivels turns.
4.It is recommended that a routine maintenance program be followed for replacement of packing and seals, What’s app +8615972752793and that regularly scheduled lubrication is preformed.

YOU LONG PETRO supplies swivel joints with the below part numbers :

We also supply a full range of genuine and interchangeable parts for SPM, FMC, SJ PETRO and other leading brands, including swivel joints, plug valves, repair kits and high-pressure valves. Whether you require standard, H₂S service or custom solutions, we have you covered.

For more oilfield parts, feel free to contact us.What’s app +8615972752793; Luben@youlongpetro.com

2″ 1502 Swivel Joints (Standard Service)
Style	Connection Type	End Type	Temperature	Service Type	Part Number
10	Hammer Union	MxF	Low Temp	Standard	2A17135
10	Hammer Union	MxM	Low Temp	Standard	2A17205
20	Hammer Union	MxF	Low Temp	Standard	2A17271
30	Hammer Union	MxF	Low Temp	Standard	2A17297
50	Hammer Union	MxF	Low Temp	Standard	2A17139
50	Hammer Union	FxF	Low Temp	Standard	2A17213
50	Hammer Union	3″ 1502M x 2″ 1502F	Low Temp	Standard	2A17327
60	Hammer Union	MxM	Low Temp	Standard	2A17293
60	Hammer Union	MxF	Low Temp	Standard	2A17494
80	Hammer Union	MxF	Low Temp	Standard	2A17289
100	Hammer Union	MxM	Low Temp	Standard	2A17274
100	Hammer Union	MxF	Low Temp	Standard	2A17272
2″ 1502 Swivel Joints (H2S Service)
Style	Connection Type	End Type	Temperature	Service Type	Part Number
10	Hammer Union	MxF	Low Temp	H2S	2A17171
10	Hammer Union	MxM	Low Temp	H2S	2A17277
20	Hammer Union	MxF	Low Temp	H2S	2A17282
30	Hammer Union	MxF	Low Temp	H2S	2A17298
50	Hammer Union	MxF	Low Temp	H2S	2A17170
50	Hammer Union	FxF	Low Temp	H2S	2A17279
100	Hammer Union	MxF	Low Temp	H2S	2A17285
3″ 1502 Swivel Joints (Standard Service)
Style	Connection Type	End Type	Temperature	Service Type	Part Number
10	Hammer Union	MxF	Low Temp	Standard	2A17920
10	Hammer Union	MxM	Low Temp	Standard	2A28766
20	Hammer Union	MxF	Low Temp	Standard	2A17671
30	Hammer Union	MxF	Low Temp	Standard	2A17947
50	Hammer Union	MxF	Low Temp	Standard	2A17922
50	Hammer Union	FxF	Low Temp	Standard	2A17280
60	Hammer Union	MxM	Low Temp	Standard	2A17953
60	Hammer Union	MxF	Low Temp	Standard	2A17970
80	Hammer Union	MxF	Low Temp	Standard	2A17934
100	Hammer Union	MxM	Low Temp	Standard	2A17937
100	Hammer Union	MxF	Low Temp	Standard	2A17955
3″ 1502 Swivel Joints (H2S Service)
Style	Connection Type	End Type	Temperature	Service Type	Part Number
10	Hammer Union	MxF	Low Temp	H2S	2A17276
10	Hammer Union	MxM	Low Temp	H2S	2A17278
50	Hammer Union	MxF	Low Temp	H2S	2A17281
100	Hammer Union	MxF	Low Temp	H2S	2A17286
4″ 1002 Swivel Joints (Standard Service)
Style	Connection Type	End Type	Temperature	Service Type	Part Number
10	Hammer Union	MxF	Low Temp	Standard	2A17925
10	Hammer Union	MxM	Low Temp	Standard	2A17929
50	Hammer Union	MxF	Low Temp	Standard	2A17926
4″ 1502 Swivel Joints (Standard Service)
Style	Connection Type	End Type	Temperature	Service Type	Part Number
10	Hammer Union	MxF	Low Temp	Standard	2A17765
10	Hammer Union	MxM	Low Temp	Standard	2A17737
50	Hammer Union	MxF	Low Temp	Standard	2A17567
