1P100080 Power End Crankshaft for TWS600S Frac Pump

描述

Frac Plunger Pump Crankshaft 1P100080 For TWS600S

The 1P100080 forged crankshaft is a core power end component engineered exclusively for the Weir SPM TWS600S triplex plunger frac pump, a 600BHP unit widely used in oilfield fracturing, acidizing and cementing operations.

Manufactured from premium AISI 4140 alloy steel via one-piece forging, this crankshaft undergoes strict heat treatment and stress relief to deliver exceptional fatigue strength and torsional resistance—critical for withstanding combined bending and torsion loads under extreme working conditions. Its precision-machined surfaces eliminate sharp edges, burrs and scratches, while optimized transition fillets and journal oil holes minimize stress concentration, the main cause of fatigue failure.

Validated by water hammer fatigue testing, the crankshaft delivers a reliable service life of approximately 500 operating hours, with enhanced resistance to torsional fatigue—the primary failure mode of high-power frac pump crankshafts. It features an integrated lubrication channel design, ensuring direct oil supply to connecting rod big-end bearings for reduced wear and prolonged service life.

As a professional manufacturer, YOU LONG PETRO adheres to strict OEM specifications and quality control standards. Each 1P100080 crankshaft is 100% inspected for dimensional accuracy and surface defects, ensuring perfect compatibility with TWS600S pumps and consistent performance in harsh oilfield environments.

YOU LONG PETRO supply durable crankshafts 100% interchangeable with the below manufacturer/OEM parts

Weir SPM TWS600/TWS600S Crankshaft assembly: 1P100080
Weir SPM TWS2250:
Weir SPM QWS1000: 1P108931
Weir SPM QWS2500SD/ QWS2500XL: 2A113295, 2P111511
Weir SPM QWS2800

HT400 Crankshaft assembly 317.55208 100058898

If you need any part numbers or other configurations of the crankshaft, contact YOU LONG PETRO for more details.

Power End

	CRANKSHAFT ASSY,WITH HEAVY DUTY BEARING,WITH OIL HOLE	P61-12-001
1	CRANKSHAFT(WITH OIL HOLE)	P60-12-014
2	BEARING,MAIN,OUTSIDE,FIXED,HEAVY DUTY	P60-12-024
3	BEARING RACE RETAINER – OUTER	P60-12-027
4	SHIM,BEARING RACE RETAINER – OUTER	P60-12-006
5	BEARING,MAIN,INSIDE FIXED,HEAVY DUTY	P60-12-025
6	BEARING,MAIN,OUTSIDE FIXED,HEAVY DUTY	P60-12-026
7	HHCS,.375-16UNCX0.88″ LG -DRILLED	P60-12-013
8	BEARING RACE RETAINER – INNER	P60-12-028
9	SHIM,BEARING RACE RETAINER – INNER,0.04″ THICK	P60-12-016
10	SHIM,BEARING RACE RETAINER – INNER,0.02″ THICK	P60-12-017
11	SHIM,BEARING RACE RETAINER – INNER	P60-12-015
12	BUSHING,MAGNETIC,SEAL INSULATOR	P15-03-031
13	O-RING,	000N569120
14	RING,SEAL	P15-04-031
15	O-RING,	000N569126
16	SEAL,MAGNETIC,SHAFT,MSC,65152 REV B	P15-05-031
17	RING,RETAINING	P15-08-031
18	OUTSIDE BEARING HOUSING GASKET	P60-12-005
19	OUTSIDE BEARING HOUSING GASKET 2.0MM	P61-12-005
20	OUTSIDE BEARING HOUSING	P61-12-002
21	STUD,BEARING RETAINER HOUSING, 7/8″X9NCX3″LG	P60-12-010
22	WASHER, LOCK, NORD-LOCK, 7/8″(NL22SP)	X20-28-541
23	NUT,HEX,7/8″-9UNC	X20-22-909
24	GASKET,INJUCTOR,CRANKSHAFT,OIL W/#20	P15-09-031
25	WASHER,LOCK,5/16″	X20-28-509
26	HHCS,5/16″-18UN 1″LONG	X20-08-576
