Item Description for 18,24 & 36 WCB
Items for Figures,4,5,6,7 & 8 for 18,24 & 36 WCB,s with screwed on linings and stop tubes
Item Desciption Item Description
1 Mounting Flange Sub-assembly 24 Waming Decal
2 Mounting Flange 25 Name Plate
3 Wear Plate 26 Drive Screw
4 Hex Head Screw 28 Gear
5 Locknut 29 Wear Spacer
6 Stud 30 Reaction Plate Sub-assembly
8 Friction Disc 31 Reaction Plate
9 Friction Disc Core 32 Decal Plate
12 Clamp Tube 33 Piston
13 Pressure Plate Sub-assembly 34 Release Spring
14 Pressure Plate 50 Inner Support Ring
17 Flat Washer 51 Outer Support Ring
18 Locknut 57 Flat Head Screw
19 Cylinder 58 Wear Ring
21 Polypak Seal 59 Stop Tube
23 Polypak Seal 80 Stop Tube
For part number listing see section 9.0
