| 2.75”FLUID END ASSY: | |||
| Item | Part | Qty | Description |
| P60-27-000 | FLUID END ASSY,234”,600HP PUMP | ||
| 0001 | P60-30-105 | 3.0000 | D-RING,DISCHARGE COVER SEAL |
| 0002 | P60-30-103 | 1.0000 | DISCHARGE COVER GAUGE |
| 0003 | P60-34-104 | 3.0000 | SEAL RING,2″ |
| 0004* | P60-30-201 | 2.0000 | DISCHARGE FLANGE |
| 0005 | P60-34-206 | 2.0000 | SEAL,POLYPAK |
| 0006 | 000P569235 | 2.0000 | O-RING |
| 0007 | P60-34-214 | 8.0000 | NUT,1″-8NC, |
| 0008 | P60-34-215 | 8.0000 | DISCHARGE FLANGE STUD |
| 0009 | P60-34-311 | 1.0000 | MANIFOLD,TPA600 PUMP |
| 0010 | X20-08-010 | 12.0000 | HHCS,750-10UNCX1.5°, |
| 0011 | P60-30-401 | 2.0000 | DISCHARGE COVER |
| 0012 | P60-30-004 | 6.0000 | VALVE SPRING |
| 0013 | P60-30-005 | 1.0000 | FLUID CYLINDER,3”TPD600-CARBON |
| 0014** | P60-27-006 | 3.0000 | PLUNGER,2.75 |
| 0015 | P8T0005275 | 3.0000 | PACKING,SPS,ASSY,2.750,600 PUMP |
| 0016 | P60-30-007 | 3.0000 | SUCTION VALVE STOP,2.75″-3″ |
| 0017 | P60-30-601 | 6.0000 | INSERT,VALVE,3” |
| 0018 | P60-30-602 | 6.0000 | VALVE,BODY(23/4″-3) |
| 0019 | P60-30-008 | 6.0000 | VALVE SEAT,2.75-3” |
| 0020 | 000P569244 | 3.0000 | O-RING |
| 0021 | 000P569146 | 6.0000 | O-RING |
| 0022 | P60-30-701 | 3.0000 | SUCTION COVER |
| 0023 | 7000010735 | 3.0000 | D-RING,SUCTION COVER,3” |
| 0024 | P60-30-011 | 5.0000 | COVER RETAINER NUT |
| 0025 | P60-27-820 | 3.0000 | SEAL,SET,ASSY(2.75) |
| 0026 | P60-34-012 | 4.0000 | SCREW,TPFS,1″-12UNFX11.00°LG, |
| 0027 | P60-34-013 | 4.0000 | SCREW,TPFS,1-3/8″-12UNFX10.50″LG |
| 0028 | P60-34-015 | 3.0000 | ASSY,PLUNGER STUD |
| 0029 | P60-27-502 | 3.0000 | NUT,PACKING,2.75” |
| 0030 | X26-02-009 | 24.0000 | PLUG,CS,1/4″NPT |
| *When use the longer discharge flange: 0004 P61-34-200 2 DISCHARGE FLANGE ASSY |
|||
| **When use the extended pump: | |||
| 0014 P62-27-006 3 PLUNGER,2.75″ | |||
| 3.5”FLUIDENDASSY | |||
| Item | Part | Qty | Description |
| P60-34-000 | FLUID END ASSY,3.5,TPD600,CARBON | ||
| 0001 | 7000014374 | 3.0000 | D-RING |
| 0002 | P61-34-103 | 1.0000 | GAUGE COVER |
| 0003 | P60-34-104 | 3.0000 | SEAL RING,2”, |
| 0004* | P60-30-201 | 2.0000 | DISCHARGE FLANGE |
| 0005 | P60-34-206 | 2.0000 | SEAL,POLYPAK |
| 0006 | 000P569235 | 2.0000 | O-RING, |
| 0007 | P60-34-214 | 8.0000 | NUT,1″-8NC, |
| 0008 | P60-34-215 | 8.0000 | DISCHARGE FLANGE STUD |
| 0009 | P60-34-311 | 1.0000 | MANIFOLD,TPA600 PUMP |
| 0010 | X20-08-010 | 12.0000 | HHCS,.750-10UNCX1.5, |
| 0011 | P61-34-401 | 2.0000 | DISCHARGE COVER,4340 |
| 0012 | P60-34-004 | 3.0000 | VALVE SPRING |
| 0012* | P60-34-017 | 3.0000 | VALVE SPRING(LIGHT) |
| 0013 | P60-34-005 | 1.0000 | FLUID CYLINDER,3.5-4.5″,TPD 600-CARBON |
| 0014** | P60-34-006 | 3.0000 | PLUNGER,31/2 |
| 0015 | P8T0005350 | 3.0000 | PACKING,SPS,ASSY,3.500,600 PUMP |
| 0016 | P60-34-007 | 3.0000 | SUCTION VALVE STOP |
| 0017 | P60-34-601 | 6.0000 | VALVE INSERT,31/2”,4”&41/2” |
| 0018 | P60-34-602 | 6.0000 | BODY,VALVE 3-1//2”4”&4-1/2″ |
| 0019 | P60-34-008 | 6.0000 | VALVE SEAT,31/2”,4”&4-1/2” |
| 0020 | 000P569244 | 3.0000 | O-RING |
| 0021 | 000P569153 | 6.0000 | O-RING, |
| 0022 | P61-34-702 | 3.0000 | SUCTION COVER RETAINER NUT,4340 |
| 0023 | 7000014375 | 3.0000 | D-RING |
| 0024 | P61-34-011 | 5.0000 | SUCTION COVER RETAINER NUT,4340 |
| 0025 | P60-34-840 | 3.0000 | SEAL,SET,ASSY,3.5″ |
| 0026 | P60-34-012 | 4.0000 | SCREW,TPFS,1-12UNFX11.00″LG, |
| 0027 | P60-34-013 | 4.0000 | SCREW,TPFS,1-3/8″-12UNFX10.50°”LG, |
| 0028 | P60-34-015 | 3.0000 | ASSY,PLUNGER STUD |
| 0029 | P06-00-063 | 3.0000 | NUT,PACKING,3-1/2 |
| 0030 | X26-02-009 | 24.0000 | PLUG,CS,1/4″NPT |
| *When use the longer discharge flange: 0004 P61-34-200 2 DISCHARGE FLANGE ASSY |
|||
| **When use the extended pump: | |||
| 0014 P62-34-006 3 PLUNGER,3.5° | |||
| 4”FLUID ENDASSY | |||
| Item | Part | Qty | Description |
| P60-40-000 | FLUID END ASSY,4″TPD600-CARBON | ||
| 0001 | 7000014374 | 3.0000 | D-RING |
| 0002 | P61-34-103 | 1.0000 | GAUGE COVER |
| 0003 | P60-34-104 | 3.0000 | SEAL RING,2” |
| 0004* | P60-30-201 | 2.0000 | DISCHARGE FLANGE |
| 0005 | P60-34-206 | 2.0000 | SEAL,POLYPAK |
| 0006 | 000P569235 | 2.0000 | O-RING |
| 0007 | P60-34-214 | 8.0000 | NUT,1″-8NC |
| 0008 | P60-34-215 | 8.0000 | DISCHARGE FLANGE STUD |
| 0009 | P60-34-311 | 1.0000 | MANIFOLD,TPA600 PUMP |
| 0010 | X20-08-010 | 12.0000 | HHCS,.750-10UNCX1.5″, |
| 0011 | P61-34-401 | 2.0000 | DISCHARGE COVER,4340 |
| 0012 | P60-40-004 | 3.0000 | VALVE SPRING,4″FLUIDEND,DISCHARGE |
| 0012* | P60-34-004 | 3.0000 | VALVE SPRING |
| 0013 | P60-34-005 | 1.0000 | FLUID CYLINDER,3.5-4.5″,TPD 600-CARBON |
| 0014** | P60-40-006 | 3.0000 | PLUNGER,4″ |
| 0015 | P8T0005400 | 3.0000 | PACKING,SPS,ASSY,4.000,600 PUMP |
| 0016 | P60-34-007 | 3.0000 | SUCTION VALVE STOP |
| 0017 | P60-34-601 | 6.0000 | VALVE INSERT,31/2”,4”&41/2” |
| 0018 | P60-34-602 | 6.0000 | BODY,VALVE 3-1//2”4”&4-1/2″ |
| 0019 | P60-34-008 | 6.0000 | VALVE SEAT,31/2”,4”&4-1/2” |
| 0020 | 000P569244 | 3.0000 | O-RING, |
| 0021 | 000P569153 | 6.0000 | O-RING, |
| 0022 | P61-34-702 | 3.0000 | SUCTION COVER RETAINER NUT,4340 |
| 0023 | 7000014375 | 3.0000 | D-RING |
| 0024 | P61-34-011 | 5.0000 | SUCTION COVER RETAINER NUT,4340 |
| 0025 | P60-40-820 | 3.0000 | SEAL,SET,ASSY |
| 0026 | P60-34-012 | 4.0000 | SCREW,TPFS,1-12UNFX11.00″LG, |
| 0027 | P60-34-013 | 4.0000 | SCREW,TPFS,1-3/8″-12UNFX10.50°LG, |
| 0028 | P60-34-015 | 3.0000 | ASSY,PLUNGER STUD |
| 0029 | P06-00-065 | 3.0000 | NUT,PACKING,4° |
| 0030 | X26-02-009 | 24.0000 | PLUG,CS,1/4″NPT |
| *When use the longer discharge flange: 0004 P61-34-200 2 DISCHARGE FLANGE ASSY |
|||
| **When use the extended pump: 0014 P62-40-006 3 PLUNGER,4″ |
|||
| 41/2”FLUID ENDASSY | |||
| Item | Part | Qty | Description |
| P60-44-000 | FLUID END ASSY,41/2”,TPD600-CARBON | ||
| 0001 | 7000014374 | 3.0000 | D-RING 3.620”IDX.368″CSX.497 HT MOLDED |
| 0002 | P61-34-103 | 1.0000 | GAUGE COVER W/2” |
| 0003 | P60-34-104 | 3.0000 | SEAL RING,2 |
| 0004° | P60-30-201 | 2.0000 | DISCHARGE FLANGE |
| 0005 | P60-34-206 | 2.0000 | SEAL,POLYPAK |
| 0006 | 000P569235 | 2.0000 | O-RING |
| 0007 | P60-34-214 | 8.0000 | NUT,1″-8NC, |
| 0008 | P60-34-215 | 8.0000 | DISCHARGE FLANGE STUD |
| 0009 | P60-34-311 | 1.0000 | MANIFOLD,TPA600 PUMP |
| 0010 | X20-08-010 | 12.0000 | HHCS,750-10UNCX1.5″, |
| 0011 | P61-34-401 | 2.0000 | DISCHARGE COVER,4340 |
| 0012 | P60-44-004 | 3.0000 | VALVE SPRING |
| 0012* | P60-34-004 | 3.0000 | VALVE SPRING |
| 0013 | P60-34-005 | 1.0000 | FLUID CYLINDER,3.5-4.5”,TPD 600-CARBON |
| 0014 | P60-44-006 | 3.0000 | PLUNGER,41/2” |
| 0015 | P8T0005450 | 3.0000 | PACKING,SPS,ASSY,4.500,600 PUMP |
| 0016 | P60-34-007 | 3.0000 | SUCTION VALVE STOP |
| 0017 | P60-34-601 | 6.0000 | VALVE INSERT,31/2”,4″&41/2″ |
| 0018 | P60-34-602 | 6.0000 | BODY,VALVE 3-1//2”4”&4-1/2 |
| 0019 | P60-34-008 | 6.0000 | VALVE SEAT,31/2”,4″&4-1/2″ |
| 0020 | 000P569244 | 3.0000 | O-RING, |
| 0021 | 000P569153 | 6.0000 | O-RING |
| 0022 | P61-34-702 | 3.0000 | SUCTION COVER RETAINER NUT, |
| 0023 | 7000014375 | 3.0000 | D-RING |
| 0024 | P61-34-011 | 5.0000 | SUCTION COVER RETAINER NUT, |
| 0025 | P60-44-840 | 3.0000 | SEAL,SET,ASSY,4.5″ |
| 0026 | P60-34-012 | 4.0000 | SCREW,TPFS,1″-12UNFX1100″LG, |
| 0027 | P60-34-013 | 4.0000 | SCREW,TPFS,1-3/8″-12UNFX10.50″LG |
| 0028 | P60-34-015 | 3.0000 | ASSY,PLUNGER STUD |
| 0029 | P06-00-058 | 3.0000 | NUT,PACKING,4-1/2” |
| 0030 | X26-02-009 | 24.0000 | PLUG,CS,1/4″NPT |
| *When use the longer discharge flange: 0004 P61-34-200 2 DISCHARGE FLANGE ASSY |
|||
| **When use the extended pump: | |||
| 0014 P62-44-006 3 PLUNGER,4.5° | |||
| 3”FLUID ENDASSY | |||
| Item | Part | Qty | Description |
| P60-30-000 | FLUID END ASSY,3”TPD600-CARBON | ||
| 0001 | P60-30-105 | 3.0000 | D-RING,DISCHARGE COVER SEAL |
| 0002 | P60-30-103 | 1.0000 | DISCHARGE COVER GAUGE |
| 0003 | P60-34-104 | 3.0000 | SEAL RING,2” |
| 0004* | P60-30-201 | 2.0000 | DISCHARGE FLANGE |
| 0005 | P60-34-206 | 2.0000 | SEAL,POLYPAK |
| 0006 | 000P569235 | 2.0000 | O-RING, |
| 0007 | P60-34-214 | 8.0000 | NUT,1″-8NC, |
| 0008 | P60-34-215 | 8.0000 | DISCHARGE FLANGE STUD |
| 0009 | P60-34-311 | 1.0000 | MANIFOLD,TPD600 PUMP |
| 0010 | X20-08-010 | 12.0000 | HHCS,750-10UNCX1.5″, |
| 0011 | P60-30-401 | 2.0000 | DISCHARGE COVER |
| 0012 | P60-30-004 | 6.0000 | VALVE SPRING |
| 0013 | P60-30-005 | 1.0000 | FLUID CYLINDER,3”TPD600-CARBON |
| 0014** | P60-30-006 | 3.0000 | PLUNGER,3” |
| 0015 | P8T0005300 | 3.0000 | PACKING,SPS,ASSY,3.000,600 PUMP |
| 0016 | P60-30-007 | 3.0000 | SUCTION VALVE STOP,2.75-3” |
| 0017 | P60-30-601 | 6.0000 | INSERT,VALVE,3″ |
| 0018 | P60-30-602 | 6.0000 | VALVE,BODY(23/4″-3) |
| 0019 | P60-30-008 | 6.0000 | VALVE SEAT,2.75″-3″ |
| 0020 | 000P569244 | 3.0000 | O-RING, |
| 0021 | 000P569146 | 6.0000 | O-RING, |
| 0022 | P60-30-701 | 3.0000 | SUCTION COVER |
| 0023 | 7000010735 | 3.0000 | D-RING,SUCTION COVER,3″ |
| 0024 | P60-30-011 | 5.0000 | COVER RETAINER NUT |
| 0025 | P60-30-840 | 3.0000 | SEAL,SET,ASSY,3”,SS CASE |
| 0026 | P60-34-012 | 4.0000 | SCREW,TPFS,1″-12UNFX1100″LG |
| 0027 | P60-34-013 | 4.0000 | SCREW,TPFS,1-3/8″-12UNFX10.50″LG, |
| 0028 | P60-34-015 | 3.0000 | ASSY,PLUNGER STUD |
| 0029 | P06-00-060 | 3.0000 | NUT,PACKING,3” |
| 0030 | X26-02-009 | 24.0000 | PLUG,CS,1/4″NPT |
| *When use the longer discharge flange: 0004 P61-34-200 2 DISCHARGE FLANGE ASSY |
|||
| **When use the extended pump: | |||
| 0014 P62-30-006 3 PLUNGER,3″ | |||
